Model
|
40A
|
50 A
|
60 A
|
80 A
|
100 A
|
|
Charging Mode
|
MPPT Automatic Maximum Power Point Tracking
|
|
Charging Method
|
Three stages : Constant Current ( MPPT), Balanced Charging,
Floating Charge
|
|
System Type
|
12 V/ 24 V/ 48 V
|
Automatic Identification/ Manual Setting
|
|
System
Identification
Voltage Range
|
12 V System
|
DC 9 V- DC 15 V
|
|
24 V System
|
DC 18 V- DC 30 V
|
|
48 V System
|
DC 36 V- DC 60 V
|
|
Soft Start Time
|
12 V/ 24 V/ 48 V
|
≤10 s
|
|
Dynamic Response Recovery Time
|
12 V/ 24 V/ 48 V
|
≤500 us
|
|
Static Power
|
12 V/ 24 V/ 48 V
|
≤2 W
|
|
Machine Efficiency
|
12 V/ 24 V/ 48 V
|
≥96 . 5 %
|
|
PV Module Utilization
|
12 V/ 24 V/ 48 V
|
≤99 . 97 %
|
|
Input Characteristics
|
|
MPPT Operating
Voltage Range
|
12 V System
|
DC 18 V- DC 150 V
|
|
24 V System
|
DC 34 V- DC 150 V
|
|
48 V System
|
DC 65 V- DC 150 V
|
|
Input Low Voltage
Protection Point
|
12 V System
|
DC 16 V
|
|
24 V System
|
DC 30 V
|
|
48 V System
|
DC 60 V
|
|
Input Low Voltage
Recovery Point
|
12 V System
|
DC 18 V
|
|
24 V System
|
DC 34 V
|
|
48 V System
|
DC 65 V
|
|
Limit Input Voltage
|
12 V/ 24 V/ 48 V
|
DC 160 V
|
|
Overvoltage Protection
|
12 V/ 24 V/ 48 V
|
DC 150 V
|
|
Overvoltage Recovery
|
12 V/ 24 V/ 48 V
|
DC 145 V
|
|
Maximum Solar
Panel Input Power
|
12 V System
|
420W
|
570W
|
700W
|
900W
|
1100W
|
|
24 V System
|
840W
|
1130W
|
1400W
|
1700W
|
2200W
|
|
48 V System
|
1650W
|
2270W
|
2800W
|
3400W
|
4400W
|
|
Output Characteristics
|
|
Optional Battery Type (Default is lead - acid maintenance- free
battery)
|
12 V/ 24 V/ 48 V
|
Lead- acid maintenance- free Battery, G e l Battery, Liquid Battery, Lithium Battery ( Can also be customized for other types of
battery)
|
