1200va 2400va MPPT solar inverter hybrid off grid inverter dc12v 24v 220vac

Product No.：008
Online Inquiry

Related Products

Off grid hybrid MPPT solar inverter 1200va 2400va

The Victor XM series is designed to power your home appliances or precious 3C electronics. It also can handle motor-type loads with high surge power such as vacuums, small freezers, or drills. With built-in solar charger, it can convert solar power to battery power and provide continuous power to connected equipment during night time.

Model	Victor XM-1200-12	Victor XM-2400-24
RATED POWER	1200VA/800W	2400VA/1500W
INPUT
Voltage	230 VAC
Selectable Voltage Range	170-280 VAC (UPS mode)
	90-280 VAC (INV. Mode)
Frequency Range	50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)	230VAC ± 10%
Transfer Time	20 ms typical
Waveform	Simulated Sine Wave
BATTERY & AC CHARGER
Battery Voltage	12 VDC	24 VDC
Floating Charge Voltage	13.7 VDC ±0.25 VDC	27.4 VDC ±0.5 VDC
Maximum Charge Current	10A or 20A
SOLAR CHARGER
System Voltage	12VDC	24VDC
MPPT rated power	500W	1000W
Operating Voltage Range	15~80 VDC	30~80 VDC
Maximum Charging Current	40A
Max. PV Array Open Circuit Voltage	102 VDC
PHYSICAL
Dimension, D x W x H (mm)	282 X 221 X 73
Net Weight (kgs)	3.2	3.5
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	0°C - 55°C
Storage Temperature	–15°C - 60°C
